Xiamen,Fujian, China |
| Brand Name: | Leaka |
| Model Number: | SP21 |
| Type: | BNC |
| Application: | Power |
| Gender: | male/female |
| Coupling: | Threaded |
| Rated voltage : | 500/400V |
| Temperature Range: | -40℃~+85℃ |
| Termination: | Solder / Crimp / Screw |
| Mating Cycles: | 500 |
| Cable outer diameter range: | SP21: 4.5-7mm , 7-12mm |
| Contact material: | Brass Gold Plated |
| Insert material: | PPS,max temperature 260℃ |
| Shell material: | PC, Nylon66, fire resistance: V-0 |
| Payment terms: | 100% T/T, Western Union , Paypal,Mastercard crecit card,VISA,e-Checking |
| Coupling | Threaded |
| Shell material | PC: Panel connector shell, Inser housing shell Nylone66: Locking nut , Back shell, Compressing nut,Retaining nut Fire resistance: V-0 |
| Insert material | PPS, max temperature260℃ |
| Contact material | Brass with gold plating |
| Termination | Solder: SP11, SP13, SP17, SP21,SP29 Crimp: SP17, SP21, SP29 Screw: SP21,SP29 (∅2.5，∅3，∅3.5mm contact) |
| IP rating | IP68 |
| Mating cycle | 500 |
| Temperature range | -40℃~+85℃ |
| Insulation resistance (MΩ) | 2000 |
