1. Product Introduction
M12 circular connectors can be divided into straight type, right angle type and panel mounted type according to their appearance, and there are also forms with and without cables. The cores manufactured according to international standards include 2Pin, 3Pin, 4pin, 5pin, 8pin and 12pin. According to international standards, it is used in various fields and is one of the main electronic components connecting power supply and signal in industry.
2. Product Parameters
|
Product Name |
M12 elbow sensor waterproof connector |
|
Contact Number |
3, 4, 5, 8, 12 Pin |
|
Contact Material |
Copper |
|
Protection Degree |
IP67 |
|
Manufacturing Process |
Injection Molding |
|
Rated Current |
3~5A |
|
Rated Voltage |
125~260V |
|
Temperature Range |
-25℃~+85℃ |
|
Appplication |
Sensors and some other devices |
