Dealers High Voltage 90 Degree Angle Energy Storage Connectors
The bolt star energy storage connector has strong current carrying capacity, can function for a long time, and the connection part is not easy to fail. The quick-plug energy storage connector is divided into two parts, a socket and a plug, with an interlocking function.
When the energy storage of the connector terminal board end socket and plug plug connection, by setting the terminal outer sleeve with the plate inner sleeve socket connection, can reduce the influence of external force to the terminal plug, and shook the terminal plug affected by external force in the risk of an, can improve the terminal board end socket and plug plug stability, ensure stable current transmission.
Product Parameter
| Rated Current | 120A |
| Rated Voltage | 1500V |
| Contact Resistant | 0.5mΩ |
| Flammability Rating | UL94-V0 |
| Protection Degree | IP50 |
| Wire Gauge | 16/25m㎡ |
| Terminal Spec | Φ5.7 |
| Temperature Range | -40℃~+125℃ |
| Service Life | 15 Years |
| Material | PA66 & T2 Copper |
| Application | Power Battery, Energy Storage Battery, Telecom Base Station Energy Storage |
| Color | Orange, Black |
Express & Payment
Company Profile
Customized--We are the manufacturer! sample &OEM&ODM are available!
Safety--We have own test chart, all of our products have been rigorously tested in the factory.
Certification--We have CE and quality management system certification.
High Quality --Our company uses the most advanced equipment to make the best quality products.
